Surface Design by "texture"
"average " -
Weighted average for normal, pigment and texture
The Syntax of "average" is similar to this of "color_map", "pigment_map" etc.
But: The first values behind the "["-brakets have the meaning of factors of how much of this
is to apply! According to this factors the listed pigments and patterns are averaged!
"average" can be used with pigment_map as well as with normal_map or texture_map in the according way.
Sample "average" with "pigment-map" :
sphere{<0,0,0>,0.8 scale <1.5,1,1> translate<0.2,1.1,0>
texture{
pigment {average turbulence 0.75
pigment_map{
[3 color Yellow] // Gewichtung, Pigment
[3 Candy_Cane translate<-10,-10,-10> ]
[5 color Clear ]
} // end of pigment_map
scale 0.5 } // end of pigment
finish {ambient 0.1 diffuse 0.9 phong 0.5}
} // end of texture
interior{ caustics 0.5 }
clipped_by{sphere{< 0.5,1,0.5>,1.25}}
}// end of sphere ------------------------------ |
Sample "average" with "texture-map" :
sphere{<0,0,0>,1.0 scale <1,0.8,1> translate<0,1.5,0>
texture{ average turbulence 0.75
texture_map{
[5 Peel scale 0.25 translate<-30,-30,-30> ]
[1 Polished_Chrome
normal{bumps 1.5 scale 0.05} ]
[3 pigment{color rgb<1,0.8,0> filter 0.7}
finish {ambient 0.1 diffuse 0.9 phong 0.5}]
} // end of texture_map
scale 1.5} // end of texture
} // end of sphere ------------------------------------- |
|
